Dongfeng Cummins 200 kw generator

MOQ: 2000 KG

Delivery time: 10 Day

Minlongpower offers the Weichai 200kVA diesel generator set. This generator is suitable for smaller to medium-sized applications. Weichai's technology ensures reliable power supply. The 200kVA capacity can power a variety of equipment and facilities. It is a good option for backup power in small to medium-sized businesses or for powering certain operations in a workshop or a small factory.

Previous: 310 kW Cummins Silent Generator

Next: Yuchai 500 kw generator

Leave a Message

If you have more information you would like to know, you can leave a message to us through the form below, and our staff will contact you as soon as possible

Name *

E-mail *

Phone

Company

Message *

Products

Generator

Engine

Crusher

Latest News

Agriculture Uses of Generators

Benefits of Portable Diesel-Powered Generators

3 Reasons Why a Used Backup Generator is Worth Buying

Generator Excitation Control Systems and Methods

Does Diesel Go Bad? Diesel Shelf Life Guide

product

Mobile 35 Jaw Crusher

1250 Vertical Shaft Sand Making Machine

1010 Hydraulic Box-type Sand Making Machine

750-1060 Jaw Crusher

250-1200 Fine Jaw Crusher

Prime power	Standby Power	Voltage/Phase	Hz/rpm	PF
250 kVA/ 20 0 kW	275 kVA/ 220 kW	220V ， 1/ 3	50/ 1500	0.8
Diesel Generator Set
Engine Make /Model		WeiChai WP10D264E200
Alternator Make /Model		Stamford, UCDI 274K
Control Panel		SmartGen, HGM6110
Circuit Breaker Type		3-pole manual circuit breaker
Battery		Maintenance free Lead Acid
Base Frame		Robust Structure/ Corrosion Resistant
Dimensions	Length(mm)	Width(mm)	Height(mm)	Weight(KG)
Silent Type	4000	1450	2150
Engine Specifications
Engine Make Model		WeiChai WP10D264E200
No. of Cylinders		6-Cylinder;L-type
Cycle		4 Stroke
Aspiration		Turbocharged and intercooled
Fuel System		Direct injection type
Governing Type		Mechanical pump/Electronic Governor
Displacement		9.726 L
Bore/Stroke		126 X 130 mm
Compression Ratio		17:01
Prime power		240 kW
Standby power		264 kW
Lubrication System
Oil pressure @ Idle Speed		100-250 kPa
Oil Pan Capacity High / Low		24 L
Air System
Maximum Intake Air Restriction
Dirty Filter Element		≤7kPa
Clean Filter Element		≤3.5 kPa
Intake Air Flow @PRP		1232 kg/h
Cooling System
Coolant Capacity - Engine Only		22 L
Thermostat Modulating Range		71-82 °C
Comply with Standards
GB/T 2820.1~6-2009 、 GB/T 2820.8~ 10-2002 、 GB/T 2820.12-2002 、 JB/T 10303-2001 JB/T 2819-1995 、 JB8587-1997 、 ISO8528 、 ISO3046
